PUSH BUTTON - ROUND GREEN LIGHT Exit Buttons & Break Glass
Radiant Push button Switch is a satin finish with stainless steel brush finished face plate, suitable for a variety of doors. It is with simple & ultra-narrow design, refined and elegant.
Exit Push Button Control is suitable for electrical control circuit such as doors, gates, locks anti-theft alarm, industrial control equipment and so on. User Friendly, push for opening the door.
MODEL
RD04303 : Push Button - Illuminated Green
|
SPECIFICATION
|
|
|
Model
|
RD04303
|
|
Material
|
Stainless steel brushed finish
|
|
Switch data
|
5A/250VAC
|
|
Optional Functions
|
NO/NC/COM
|
|
Suitable for Door
|
All kinds of Doors
|
|
Operating temp
|
-10
～
+55
℃
(14-131F)
|
|
Operating Humidity
|
0-95% (Non- condensing)
|
|
Dimensions
|
RD04304 - 86.8H*86.8W*23D
|
|
Weight
|
0.2Kg
|
Download Technical Datasheet PUSH BUTTON - ROUND GREEN LIGHT
